Product ID: prod-11 · PN: LTL-ADA-102
Expands an FPGA board’s I/O capability by converting the HSMC interface into configurable general-purpose input/output connections.
Product overview
The HSMC to GPIO Adapter provides configurable digital I/O lines on the FPGA side and dedicated GPIO headers for external devices. It enables direct interfacing with sensors, actuators, switches, and control circuits, while supporting optional high-speed host communication through compatible FTDI USB bridges.
Features
Core capabilities supplied for LTL-ADA-102.
Expands the FPGA board’s I/O capabilities by converting the HSMC interface into general-purpose input/output pins.
Provides configurable digital I/O lines on the FPGA side and dedicated GPIO headers on the external-device side for direct connection to sensors, actuators, switches, or control circuits.
Supports connection to compatible FTDI USB bridges, with flexible mapping options for FIFO, UART, or MPSSE modes between the FPGA and a host computer.
Supports single-ended or LVDS signaling, with data rates up to 680 Mbps per LVDS pair.
Key specifications
Downloads
Revision history
Release date and change summary require manual verification.
Engineering inquiry
